15 t Chassis Dynamometer
High-capacity 15 t chassis dynamometer for trucks and light commercial vehicles. Eddy-current control.
Dealer pricing available on request. Final price depends on configuration, delivery location, installation scope and the approval documentation required.
Extended Cartesy Europe 36 support programme available subject to registration, installation and annual service conditions.
Warranty & support →The ECTDCG-13VU is a 15 t vehicle chassis dynamometer for professional automotive workshops, used-car evaluation centres and performance tuning facilities. Eddy-current control technology delivers safe, precise data acquisition with power absorption above 300 kW and max brake torque 3000 N·m. The 373 × 1100 mm rollers and integrated flywheel inertia simulation reproduce real-road conditions, with an air-lift mechanism for quick vehicle on/off.
Full datasheet
- RollerSize
- Ø 373 × 1100 mm
- LoadCapacity
- 15,000 kg
- MaxBrakeTorque
- 3000 N·m
- PowerAbsorption
- > 300 kW
- LiftingMechanism
- Air lift
- ControlTechnology
- Electric eddy current
- InertiaSimulation
- Equipped with flywheel
- RollerCenterDistance
- 600 mm
ECTDCG-13VU · Features
- Heavy-duty 15 t platform for trucks and light commercial vehicles
- Power absorption > 300 kW, max brake torque 3000 N·m
- Eddy-current control with flywheel inertia simulation
- Air-lift mechanism for fast vehicle on/off
- Suited to dynamics, emissions, drivetrain and ECU-calibration testing
